Practical Excavator Boom Arm, Excavator Long Reach For PC200 CAT320 SK200
For more products:
Product Presentation of Excavator Boom
The excavator's extended arm is constructed using Q355B steel, which provides excellent strength and rigidity. The shaft sleeve of the extension arm is typically made of 45# steel and lined with a 40Cr bushing, which is lubricated with butter to decrease the shear force generated by frequent rotation of the shaft and sleeve. This increases the extension arm's service life. The bushing is positioned between the main body bracket and working arm and is connected and supported by an oil cylinder. The control system inside and outside the cockpit includes a set of cylinders for the extension arm working cylinder and bucket cylinder, which function in conjunction with the control arm. The telescoping capabilities of the cylinders more than double the bucket's stroke, allowing for greater reach and depth. This makes it particularly well-suited for use in mines, docks, warehouses, flood relief, and other special situations. This represents a significant advancement in mining machinery and has tremendous practical value.
| Material Use | Q345B, Q550D, Also can customize to customer requirements |
| Product Warranty Period | 6 months,9 months,1 Year |
| Product Size | Most lengths can be 34M, According to customer requirements, Any excavator model. |
Advantages of Zhonghe Excavator Long Arm
1. Less maintenance
Using high-quality materials, such as default Q355B, optional Q690D, Ningbo connectors, seamless precision pipes, graphite alloy copper sleeves, strong and lightweight barrels.
2. Sturdy and sturdy
Built-in stiffeners. Professional welding skills for different bearing positions. Groove preparation before welding (45° edge excavation).
What Zhonghe Can Do
CUSTOMIZATION:
1. Applicable for all brand excavators.
2. Color, length, and material can do according to you.
3. Extra pipelines can be added to suit some extra applications.
4. Boom cylinder and stick cylinder can also be supplied if the customer wants.
STRONG PRODUCTION CAPACITY:
We can produce 50 sets of excavator booms per month.
Our annual output of various types of excavator boom arms can reach 600 sets.
GOOD SERVICE:
1. Online support within 24 hours.
2. Appointment video technical support.
(Our engineers have focused on excavator boom and attachment for over 10 years)
3. Long excavator boom shall be two/three jointed pcs to make it fittable into a container to save shipping costs.
Warranty:
1 year for long reach boom, 180 days for cylinder and linkage, and 90 days for the bucket.
All parts you needed are included.
Long Reach Kits Are Fully Compatible with ZHONGHE Excavator Standard Buckets, and Cylinder.
| Excavator long boom | Excavator long arm | Standard bucket |
| Linkage kit | Bucket cylinder | Butter hose |
| Pin | Lubricating system | Seals |
Specification of Excavator Boom Arm
Weight | Model | Part Length | Total length(m) | Weight(kg) | Maximum removal height(m) |
| Total Length(mm) | 25T | 8.5 | 16 | 2800 | 16M |
| Boom(A)(mm) | 2.3 | 900 |
| Arm(b)(mm) | 5.2 | 1700 |
| Maximum Digger Radius(C)(mm) | 30T | 9.5 | 18 | 3000 | 18M |
| Maximum Digger Depth(C)(mm) | 2.3 | 1000 |
| Maximum Unloading Height(E)(mm) | 5.2 | 1950 |
| Maximum Digger Height(F)(mm) | 35T | 10.5 | 20 | 3500 | 20M |
| Bucket Volume(m³) | 2.3 | 1100 |
Company Strength
Kaiping Zhonghe Machinery Manufacturing Co., Ltd, is a manufacturing and trading combo that specializes in customizing different kinds of excavator boom arms and attachments We have more than 14000m' steel structure standardization workshop with a large number of high precision processing equipment as well as a strong and cohesive team. At present, there are more than 60 experienced technical staff, 30 welding workers with over 7 years of experience, 15 senior designers, and a high-tech R&D team.
Our annual output of various types of excavator boom arms can reach 600sets. We supply products with high quality and moderate prices, which sell well in more than 40 countries and areas.
We adhere to" Merit Quality, Sincerity Management, and Customer Satisfaction", and honestly greet customers from home and abroad to negotiate and cooperate with us.
Product Tags:
|
|
Practical Excavator Long Boom Arm Reach For PC200 CAT320 SK200 Images
|
